Roller Door Installation in Perth: What Happens on the Day
Old door out, guides plumbed, drum mounted, spring tensioned to the curtain, motor set and floor sealed. New roller doors, replacements and re-installs after building work, prices incl. GST.
- Perth metro, from Gosnells
- Old door removed
- 12-month workmanship warranty
- Homes, sheds and units
Installed and tensioned
Quick Answer
Roller door installation Perth-wide by Elite Garage Doors Perth covers the whole job: removing the old door, fixing new guides plumb to the opening, mounting the drum and curtain, setting the spring tension, fitting a Capital motor and sealing the floor. A new roller door installed is $3,000–$5,000 incl. GST; taking a door down and re-hanging it around building work is $880–$1,500. Free site measure, no call-out fee.
Roller door installation, step by step
A roller door install stands or falls on the opening. Before anything is fixed, the installer checks that the jambs are plumb, the lintel is straight and strong enough to carry the drum brackets, and the floor is level across the opening; a floor that falls to one side leaves a wedge of daylight under the curtain, and a lintel that is out of square makes the curtain run tight on one guide. If the opening needs packing, a new lintel plate or a bead of concrete under the seal, that is done first.
With the old door and its guides removed, the new guides are fixed to the jambs, checked for plumb and for the exact width the curtain needs, since guides set too tight bind and guides set too loose let the curtain rattle. The drum brackets are fixed to the lintel or wall, the drum and curtain are lifted onto them, and the curtain is fed into the guides. The spring inside the drum is then wound to the curtain's weight so the door holds at any height by hand. Spring tensioning is the part of the job an owner should never attempt; a wound roller door spring stores enough energy to cause serious injury, which our guide on roller door spring tension explains.
If the door is being automated, the Capital motor mounts on the drum axle, the power point and wall control are connected, and the open and close limits and the obstruction force are set so the door stops on the floor without straining and reverses if something is in the way. The bottom rail seal and any side brush seals go on last, the remotes are programmed, and you are shown the manual release.
Roller doors have honest limits. The drum takes wall space above the opening, the curtain in steel guides is noisier than a sectional door on nylon rollers, the seal at the sides is a brush rather than a rubber jamb seal, and windows or insulation are not normally available. Where those matter, our roller vs sectional comparison helps you choose, and the roller doors page covers sizes, colours and prices. If the door you have simply needs a spring, guide or lock fixed rather than replacing, see roller door repairs. We install across the metro area, including Maddington and Piara Waters.
Faults We Repair Most Often
What the Visit Covers
- Opening checked for plumb, level and lintel strength
- Old door, drum and guides removed and taken away
- New guides fixed plumb at the correct curtain clearance
- Drum brackets fixed, curtain hung and fed into the guides
- Spring tensioned so the door holds at any height by hand
- Capital motor fitted, limits and obstruction force set
- Floor seal and brush seals fitted, remotes programmed
- Manual release demonstrated, price in writing incl. GST
What Happens When You Call
Measure the opening
Width, height, drum clearance, side room and the floor line, plus the lintel and jamb fixings.
Door and motor chosen
Curtain gauge and colour, manual or Capital motor, lock and wall control decided from the measure.
Door made and delivered
The curtain and drum are made to size and the install booked once they are ready.
Install
Old door out, opening prepared, guides and drum fixed, curtain hung, spring wound, motor set, seals on.
Test and handover
Door checked by hand at several heights, then run under the motor with the reverse tested on an obstruction.
Guide Prices
Roller door installation prices in Perth are set by the door size and gauge and whether a motor is fitted. These figures come from our live price list, include GST, and are fixed after the site measure.
| Job | Guide price (incl. GST) | Notes |
|---|
Guide figures only, and every price includes GST. What you pay depends on what has failed, the parts needed and the size of the door; the technician confirms the exact price at your door before any work begins, and the quote costs nothing.
Why Perth Homes Call Elite
Opening checked first
Plumb, level and lintel strength confirmed before a single fixing goes in.
One written price
Door, motor, removal and any making-good in a single GST-inclusive figure.
Old door taken away
Curtain, drum and guides removed and disposed of as part of the install.
Motor set properly
Limits and obstruction force adjusted to the door, not left on factory defaults.
Warranted
12-month workmanship warranty on the install; 5-year motor and drive warranty on Capital openers.
Sheds and units too
Residential garages, backyard sheds and light commercial units across the metro.
Suburbs We Cover
Technicians head out from Gosnells to every part of the Perth metro, including these suburbs:
Your suburb isn't listed? Ring and check — the whole metro area is covered.
Request QuoteFrequently Asked Questions
A new residential roller door supplied and installed is $3,000–$5,000 incl. GST from our price list, including removal of the old door. Oversized or heavy-gauge doors are $5,000–$15,000. The price is fixed after a free site measure and there is no call-out fee.
Bunnings sells kit roller doors; installation, if offered, is through third parties, and we do not fit customer-supplied kits. The reason is the spring: a kit curtain still has to be tensioned to its weight and run in guides set plumb at the right clearance, and a door installed without that binds, drops or jams. We supply doors made to the measured opening and install them ourselves.
We do not install doors supplied by others, so the closest figure is a removal and re-install of your own existing door around building work, which is $880–$1,500 incl. GST. Fitting a Capital motor to a roller door that is already hung is $770–$990.
The drum needs wall space above the opening, the steel curtain in its guides runs louder than a sectional door on nylon rollers, the side seal is a brush rather than a rubber jamb seal, and insulation and windows are not normally available. In exchange you get a door that needs no ceiling space, suits sheds and carport conversions, and costs less to repair.
Most standard residential installs on a sound opening are done within a day, and a straightforward replacement is often quicker than that. Preparing a damaged lintel, packing an out-of-square opening or running a new power point for the motor adds time, which we flag at the measure.
Yes. The door is released from tension, taken off its brackets and stored, and after the trades finish it is re-hung, the spring re-wound to the curtain's weight and the motor limits reset. That removal and re-install is $880–$1,500 incl. GST. If the door is already rusted along the bottom rail, it is worth pricing a new door at the same time.
